Product Details:
Payment & Shipping Terms:
|
| Model NO.: | Customized | Opening Style: | Rolling |
|---|---|---|---|
| Opening Type: | With Remote Control | Motor Shaft: | 3.9m |
| Power: | 100W | Output Torque: | 1000N |
| Door Panel Pattern: | Linear | Color: | White |
| Surface Finishing: | Finished | Working Temperature: | -35 To 65 Celsius Degree |
| Protection Class: | IP55 | Max Size: | W8000mm*H8000mm |
| Curtain Thickness: | 0.8-1.5 Mm | Transport Package: | Wood Case |
| Specification: | JTM-D01, JTM-D02, JTM-D03, TM-D04, JTM-D05 | Trademark: | JCJS OR OEM |
| Origin: | China | HS Code: | 85308000 |
| Supply Ability: | 50000sets/Year | Package Size: | 400.00cm * 90.00cm * 60.00cm |
| Package Gross Weight: | 300.000kg | Warranty: | 1 Year |
| Material: | Aluminum Alloy | Thickness: | 40mm |
| Customization: | Available | Customized Request | Shipping Cost : | About Shipping Cost And Estimated Delivery Time. |
| : | Initial Payment Full Payment | Currency: | US$ |
| Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
| Opening Speed: | 06m-2.0m/s (Adjustable) | |||||||
| Closing speed: | 0.5m-1.5m/s (Adjustable) | |||||||
| Max dimension: | 8000mm wide*8000mm high | |||||||
| Wind resistance: | Beaufort scale 12 (35m/s) | |||||||
| Control system: | Servo type | |||||||
| Driving system: | Servo motor | |||||||
| Motor Side | Left/Right, Left and Right | |||||||
| Sound insulation factor: | R=25dB | |||||||
| Power supply: | 1-phase 220±10%V,50/60HZ, | |||||||
| or 3-phase 380V±10%V,50/60HZ | ||||||||
| Available colors: | Red,Grey,Orange,Champagne, Yelleow,White,Blue,Silver,Brown | |||||||
High Speed Door Beneficial:
1.Improve transport efficiency.
Especially for the traffic busy entrance ,the high speed door will great reduce the forklift or human waiting time ,great improve the transport efficiency ,thus improve the factory production efficient .
2.High level cleanness .
Our high speed door comply with GMP Standard ,easy to clean.
Great improve indoor environment cleanness ,inject the dust or insect into the workshop.
Widely used in the Printing and precision machinery industry, food or Pharmaceutical Industry,clean room ,and where there is high requirement of the cleanness .
3.Effective Insulation,super seal,Energy saving .
High speed opening and close and super seal will keep the indoor energy or cold air ,save the energy cost for the owner.Widely used for where there is temperature difference area.
4.Intelligent automation.
Standard operation : Two sides push button can meet the basic daily needs .
Additional operation way: Radar sensor ,Vehicle loop detector ,remote control ,pull switch will make the transport more convenient .
It can also be Connect with the production line ,Conveyor belt,VGA Vehicle and so on ,realize the automation intelligent work flow.
5..Excellent user safety performance.
Bottom soft wireless safety edge ,photos sensor ,Warning lamp are always the standard configuration.
6.Highly Customized.
We will according to the door application special customize the door for you.
Example :All 304 stainless steel structure for food or pharmaceutical industry ,Aluminum Alloy frame for the outside bad weather ,different color fit for your building environment ,etc.
A 7-10 days for production ......
Q How about the after sale service?
A Spare parts will be delivery out within 24 hours by DHL ,UPS ,TNT and so on .
Q Can we become your agent ?
A Yes ,we are very welcome new partners ,but we have to check if there is already have partners in your local area .
